SMD 功率电感器 HCDS2D-8D SERIES-CA
FEATURES
* RoHS, Halogen Free and REACH Compliance
* :: Magnetic shielded
* :: Various package sizes and wide inductance range
Include Series
| range | Length (mm) | Width (mm) | Height (mm) | Inductance (µH) | DC resistance (mΩ)Max. |
Saturation current (A) |
|---|---|---|---|---|---|---|
| HCDS2D11-CA | 3.2⁺⁰ | 3.2⁺⁰ | 1.20⁺⁰ | 1.2~22 | 68~950 | 0.18~0.72 |
| HCDS2D14-CA | 3.2⁺⁰ | 3.2⁺⁰ | 1.55⁺⁰ | 0.47~12 | 40~394 | 0.52~2.0 |
| HCDS2D18LD-CA | 3.2⁺⁰ | 3.2⁺⁰ | 2.00⁺⁰ | 2.2~47 | 41~660 | 0.21~0.85 |
| HCDS2D18HP-CA | 3.2⁺⁰ | 3.2⁺⁰ | 2.00⁺⁰ | 1.5~22 | 50~650 | 0.50~1.90 |
| HCDS3D11-CA | 4⁺⁰ | 4⁺⁰ | 1.2⁺⁰ | 2.7~39 | 78~942 | 0.14~0.53 |
| HCDS3D16-S1-CA | 4⁺⁰ | 4⁺⁰ | 1.8⁺⁰ | 1.0~100 | 40~2750 | 0.13~1.60 |
| HCDS3D28-CA | 4⁺⁰ | 4⁺⁰ | 3⁺⁰ | 1.0~47 | 45~599 | 0.48~2.80 |
| HCDS3D28LD-CA | 4⁺⁰ | 4⁺⁰ | 3⁺⁰ | 10~220 | 95~1270 | 0.116~0.50 |
| HCDS3D16-CA | 4⁺⁰ | 4⁺⁰ | 1.8⁺⁰ | 1.0~68 | 40~1700 | 0.16~1.35 |
| HCDS4D18-CA | 4.7±0.3 | 4.7±0.3 | 2.0⁺⁰ | 1.0~100 | 45~2000 | 0.20~1.72 |
| HCDS4D28-CA | 4.7±0.3 | 4.7±0.3 | 3.0⁺⁰ | 1.2~680 | 23.6~5200 | 0.10~2.56 |
| HCDS4D40-CA | 4.7±0.3 | 4.7±0.3 | 4.0⁺⁰ | 2.2~22 | 22~270 | 1.40~4.60 |
| HCDS5D18-CA | 5.7±0.3 | 5.7±0.3 | 2.0⁺⁰ | 1.0~100 | 38~1200 | 0.36~2.80 |
| HCDS5D28-CA | 5.7±0.3 | 5.7±0.3 | 3.0⁺⁰ | 1.0~560 | 15~3200 | 0.12~3.50 |
| HCDS6D28-CA | 6.7±0.3 | 6.7±0.3 | 3.0⁺⁰ | 1.0~220 | 24~1300 | 0.30~3.50 |
| HCDS6D38-CA | 7⁺⁰ | 7⁺⁰ | 4.0⁺⁰ | 2.2~560 | 18~1800 | 0.22~3.80 |
| HCDS8D43-CA | 8.3⁺⁰ | 8.3⁺⁰ | 4.5⁺⁰ | 3.3~100 | 19~353 | 1.10~5.70 |
